| Project | Parameter | |
Visible light | Optical zoom | 40 times |
Resolution | 1920x1080 | |
Focal length | 4.25~170mm | |
Field of view | 66.35°~1.90° | |
Detection range | people 11.1km； vehicles 20km | |
Recognition range | people 2.7km； vehicles 11km | |
Servo control | Course range | NX 360° |
Pitch range | -120°~40° | |
| Angular accuracy | ≤1mrad | |
| Angular velocity | ≥ 60° /s | |
Angular acceleration | ≥ 150° /s² | |
Single object tracking | Target type | General objective |
Tracking rate | ≥ 32 pixels per frame | |
Update frame rate | ≥50FPS | |
Laser ranging | band |
|
| Ranging range | 50m~5000m | |
| Ranging accuracy | ±1m | |
| Ranging frequency | 1 ~10Hz | |
| Size and weight | Size | ≤ Ф155mmX205mm |
| Weight | ≤ 2.2kg | |
Thermal imaging | Working band | 8μm~14μm |
| Resolution | 640x512 | |
| Pixel size | 12μm | |
| Focal length | 55mm/F1.0 | |
| Field of view | 8°x6.4° | |
| Detection range | people, 2.9km; vehicles (<3mx6m), 7.0km | |
| Recognition range | people, 0.7km; vehicles (<3mx6m), 1.7km | |
Environmental | Working temperature | -40°C ~60°C |
Storage temperature | -40°C ~70°C | |
Impact | 20g/11ms | |
Multi-target tracking | Target type | People, vehicles, ships, planes |
Recall rate | ≥90% | |
Precision rate | ≥80% | |
Target size | 32x32@1080p Minimum | |
Target quantity | ≥20 | |
Jump rate | ≤15% | |
Update frame rate | ≥20FPS | |
Video and Storage | Photo format | JPEG |
Encoding format | H.264, H.265 | |
Video Protocol | RTSP, UDP, etc | |
| Video format | MP4, TS | |
Storage capacity | Maximum 2T | |
Power supply | Power supply range | 11 ~ 28 VDC |
Power consumption | 20w (Average) | |
Power consumption | 60w (Peak) | |
| Electrical interface | Communication | Serial port, Gigabit network |
| Video interface | Gigabit network, SDI | |
