| Project | Parameter | |
Visible light | Working band | 0.4μm~0.9μm |
Resolution | 1920×1080 | |
Focal length | 4.25mm to 170mm optical 40x continuous zoom | |
Field of view | 66.35°~1.90° | |
Detection range | people 11.1km, vehicles 20.0km | |
Recognition range | people 2.7km, vehicles 11.0km | |
Servo control | Course range | Nx360° |
Pitch range | -120°~+40° | |
Roll range | Limit±75° | |
| Angular velocity | ≥60°/s | |
| Angular acceleration | ≥150°/s² | |
Single target tracking | Target type | General objective |
Tracking rate | ≥ 32 pixels per frame | |
Update frame rate | ≥50FPS | |
| Laser ranging | band | 1535nm |
| Ranging range | 6km | |
Ranging accuracy | ±1m | |
| Ranging frequency | 1~10Hz | |
| Thermal imaging | Working band | 8μm ~ 14μm |
| Resolution | 640×512 | |
| Pixel size | 12μm | |
| NETD | ≤ 40mK | |
| Focal length | 55mm | |
| Field of view | 8.0°x6.4° | |
| Detection range | people 2.9km vehicles 7.0km | |
| Recognition range | people 0.7km vehicles 1.7km | |
| Size and weight | Size | ≤ Ф135mmX194mm |
| Weight | ≤ 1.5kg | |
| Environmental | Working temperature | -20°C~+ 60°C |
| Storage temperature | -45°C~ +70°C | |
Multi-target tracking | Target type | People, vehicles, ships, planes |
Recall rate | ≥90% | |
Precision rate | ≥80% | |
Target size | Minimum 32x32@1080p | |
Target quantity | ≥20 | |
Jump rate | ≤15% | |
Update frame rate | ≥20FPS | |
Video and Storage | Photo format | JPEG |
Video format | MP4 | |
Encoding format | H.264, H.265 | |
Video Protocol | RTSP, UDP, etc | |
Storage capacity | Maximum 2T | |
Power supply | Power supply range | 11 ~ 28VDC |
Power consumption | 20w (Average ) | |
Power consumption | 50W (Peak) | |
| Electrical interface | Communication | Serial port, 100-megabit network, SBUS |
| Video interface | 100-megabit network | |
